DD220R

319,00

DD220R

2 DIN media station with GPS navigation module and android smart mirroring

€ 319.00

6.8 ” media station with GPS navigation ready, Android Smart mirroring and DSP with 24-bit DAC

DATA SHEET

OWNER MANUAL

Description

2 DIN media station with 6.8 ”capacitive touch screen in high-definition with a new 32-bit panel, which implies into more clean images, greater contrast and millions shades of colors.

DD220R includes the last generation navigation module with GPS antenna, to take you safely to your destination while enjoying your trip listening your favorite music in high definition , thanks to its powerful 24-bit digital sound processor, 13-band equalizer with adjustable in frequency and slope, so like an active crossover and time alignment processor with a powerful 4x50w amplifier for superior sound quality.

At the connectivity level, DD220R has 1 USB rear port for  audio/ video files player, even high resolution files compatibility , allowing you to play FLAC files or even WAV at 192Khz/24 bit. It also has Bluetooth 4.0 with audiostreaming and voice control for apple devices.

Regarding expansion , the media station is equipped with Android Smart mirroring, being able to duplicate  your Android phone on its 6.8 ″ display and control  it with touch control. It also has inputs for connect a rear view camera, DVR camera, steering wheel control and other AV inputs and outputs.

In resume, one of the 2 DIN media station with the best value for money on the market.

Specs

MODEL DD220R
 Operating system: Windows CE 6.0
CPU Multicore
Program laguage English, French, Spanish, Portuguese, German
CD/DVD: No
Buttons ligth: White
Size: 2 DIN / 80mm. Depth
Display: 800×480 WVGA  32 bit
Screen size: 6.8″
Touch panel: Yes / Capacitive
Navigation function: Yes, GPS antenna included
Memory: Internal flash
Remote control: No
Steering wheel buttons compatible Yes – programmable.
CONECTIVITY
Wifi No
Bluetooth: Yes, ver.4.1
Microphone type: External included
Audiostreaming A2DP: Yes
Smart mirroring: OS Android
System compatibility Android 5.1 or higher with touch control
Carplay & Android Auto No
USB 1 rear USB
SD No
microSD Yes, frontal, for maps
RADIO
Radio: FM / AM
DAB: No
DABAntenna : No
Presets: 18 FM, / 12 AM
RDS: Yes
CONNECTIONS
Inputs: 1 rear AV
Vídeo outputs: 1
Audio outputs: 3 RCA  2 Volts.( Front /Rear / Subwoofer).
Subwoofer output: Yes
PIP No
Camera input Yes
DAB input No
DTV input No
DVR input Yes
SOUND
Max. power: 4x50W
Digital sound processor (DSP) Yes, 24- bit high resolution
 Active Crossover Yes
Time alignement Yes
Loudness: Yes
Subwoofer Control: Yes
Ecualizer: 13 Bands
SUPPORTED FORMATS
 Audio Mp3/ WMA/ WAV/VBR/ FLAC/ AAC / M4A.
 Vídeo .avi /.mp4/.mpg 1-2-4/ H264/ .mkv/ .wmv
Ref: EV-50-90220 Categories: ,
